灯丝电压 U f………………………….........................10 V If…………………………............................3.25 A 极限额定值 阳极电压…………………………..............1250 V 阳极耗散功率…………………………........75 W 最大讯号时输出功率……………….......150 W 阳极最大电流………………………….......120 mA 极间电容 输入电容…………………………................6 PF 输出电容…………………………...............4.5 PF 跨路电容…………………………...............14.5 PF 静态参数 Ua………………………….........................1250 V Ug…………………………..........................-200 V Ia…………………………............................80 mA Gm…………………………..........................3 mA/V ri……………………….................................1.7 KΩ µ…………………………...............................5 RL………………………................................3.4 KΩ Ug(pk) ………………................................69 V Pout………………………….........................15 W |
