灯丝电压 Uf…………………………............................. 5 V If…………………………..............................1.2 A 极限额定值 阳极电压…………………………................480 V 阳极耗散功率……………………............. 40 W 阴极电流 自偏压…………………………...................100 mA 固定偏压…………………………................70 mA 极间电容 输入电容…………………………...................9 PF 输出电容………………………...................4.3 PF 跨路电容………………………….................15 PF 静态参数 Ua…………………………............................300 V Ug………………………..............................- 60 V Ia…………………………............................60 mA Gm………………………….........................5.5 mA/V Ri…………………………............................0.7 KΩ μ…………………………..........................3.85 Pout………………………..........................6.6 W |
