灯丝电压 Uf…………………………..........................10 V If…………………………...........................3.25 A 极间电容 输入电容…………………………..............6 PF 输出电容…………………………..............5.5 PF 跨路电容………………………….............14.5 PF 静态参数 Ua………………………….......................1250 V Ug…………………………........................-70 V Ia………………………….........................100 mA Gm………………………….......................3.8 mA/V µ(当Ia=75mA时) …………………….....12 RL………………………............................ 7 KΩ Pout…………………………......................10 W |
